    • The best LED replacement for HID and SON road lamps with TrueForce LED

      MAS LED SON-T IF 10.8Klm 65W 727 E40
      LED
      MAS LED SON-T IF 10.8Klm 65W 727 E40
      MASTER - LED HID SON-T

      MAS LED SON-T IF 10.8Klm 65W 727 E40

    Specifications Show all

    Operating and Electrical
    Lamp Current (Nom)
    1,760 mA
    Power Consumption
    65 W
    Voltage (Nom)
    80-90 V
    Wattage Equivalent
    150 W
    Starting Time (Nom)
    0.5 s
    Warm-up time to 60% light
    0.5 s
    Line Frequency
    50 Hz
    Input Frequency
    50 Hz
    Product Data
    Order product name
    MAS LED SON-T IF 10.8Klm 65W 727 E40
    Order code
    44899500
    Full product code
    871951444899500
    Material number (12NC)
    929003467612
    Full product name
    MAS LED SON-T IF 10.8Klm 65W 727 E40
    Numerator - Packs per outer box
    6
    Numerator - Quantity Per Pack
    1
    EAN/UPC - Case
    8719514449008
    Approval and Application
    Energy Efficiency Class
    D
    EPREL Registration Number
    1077807
    Energy Consumption kWh/1000 h
    65 kWh
    EU RoHS compliant
    Yes
    Controls and Dimming
    Dimmable
    No
    General Information
    Switching Cycle
    50,000
    Flux measurement reference
    Sphere
    Cap-Base
    E40  [E40]
    Lighting Technology
    LED
    Nominal lifetime
    70,000 hour(s)
    Mechanical and Housing
    Bulb Material
    Glass
    Bulb Finish
    Clear
    Bulb Shape
    T70  [T 70mm]
    Temperature
    Ambient temperature range
    -40 °C to 55 °C
    T-Case Maximum (Nom)
    55 °C
    Light Technical
    Color Designation
    Warm White (WW)
    Correlated Color Temperature (Nom)
    2700 K
    Color Code
    727  [CCT of 2700K]
    Luminous Efficacy (rated) (Nom)
    166 lm/W
    Color Consistency
    <6
    Luminous Flux
    10,800 lumen
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Color rendering index (CRI)
    70

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     E40 T 70mm Clear
    E40 T 70mm Clear
    E40
    E40
    Performance Diagrams
    Lumen Maintenance Diagram - MAS LED SON-T IF 10.8Klm 65W 727 E40
    Lumen Maintenance Diagram - MAS LED SON-T IF 10.8Klm 65W 727 E40
    Life Expectancy Diagram - MAS LED SON-T IF 10.8Klm 65W 727 E40
    Life Expectancy Diagram - MAS LED SON-T IF 10.8Klm 65W 727 E40
    Photometrics
    General uniform lighting - MAS LED SON-T IF 10.8Klm 65W 727 E40
    General uniform lighting - MAS LED SON-T IF 10.8Klm 65W 727 E40
    Spectral Power Distribution Colour
    Spectral Power Distribution Colour
    Light Distribution Diagram
    Light Distribution Diagram
    Downloads
    Product Data Sheet
    Green Data
    Visuals
    Brochures
    Software Plugins
    • IES IES File IES 30.8 kB
