    • Reliable, high performance technology for extreme LED applications

      Xi LP 150W 0.5-1.5A S1 230V S240 sXt
      LED
      Xi LP 150W 0.5-1.5A S1 230V S240 sXt
      Xitanium LED drivers - lite programmable

      Xi LP 150W 0.5-1.5A S1 230V S240 sXt

    Specifications Show all

    Operating and Electrical
    Diagnostics
    True
    Output Current (Min)
    150 mA
    Inrush Current Width to 50% of Peak
    300 µs
    Output Power (Max)
    150 W
    Open Circuit Voltage (DC) (Max)
    200 V
    Output Power (Min)
    7.5 W
    Output Current (Max)
    1500 mA
    Maximum Efficiency at Full Load
    85 %
    Output Voltage (Min)
    50 V
    Inrush Current Peak (Max)
    53 A
    Output Current Ripple (Max)
    4 %
    Output Voltage (Max)
    142 V
    Product Data
    Order product name
    Xi LP 150W 0.5-1.5A S1 230V S240 sXt
    Order code
    69150200
    Full product code
    871869669150200
    Material number (12NC)
    929001553806
    Full product name
    Xi LP 150W 0.5-1.5A S1 230V S240 sXt
    Numerator - Packs per outer box
    10
    Numerator - Quantity Per Pack
    1
    EAN/UPC - Case
    8718696691519
    Approval and Application
    Protection class IEC
    Safety class I/II
    Isolation Classification
    Class I and Class II
    Ingress protection code
    IP20  [Finger-protected]
    Surge Protection (Common/Differential)
    Luminaire surge protection level until 6 kV differential mode and 10 kV common mode
    Approval Marks
    CCC certificate
    CE marking
    CB Certificate
    ENEC certificate
    Output Current Set Options
    SimpleSet
    Controls and Dimming
    D4i compliant
    No
    DynaDimmer
    Yes
    Constant light output
    Yes
    Dimmable
    1-10V
    Dimming Range
    100-10 %
    General Information
    Lighting Technology
    LED
    Nominal lifetime
    100,000 hour(s)
    Mechanical and Housing
    Overall length
    240 mm
    Dimensions (Height x Width x Depth)
    38 x 60 x 240 mm
    Overall height
    37.8 mm
    Housing
    S240
    Overall width
    59.7 mm
    Product Length
    240 mm
    Temperature
    T-Case Maximum (Max)
    90 °C
    T-Case Lifetime (Max)
    80 °C
    System characteristics
    Central DC Operation
    No
    YellowDot ready
    No
