XITANIUM 50W WH 0.7-1.5A 54V TD/IS

Specifications Show all

Operating and Electrical

Output Current (Min)	700 mA
Output Power (Max)	50 W
Open Circuit Voltage (DC) (Max)	60 V
Output Power (Min)	17 W
Output Current (Max)	1500 mA
Output Voltage (Min)	24 V
Output Current Ripple (Max)	4 %
Output Voltage (Max)	54 V

Product Data

Order product name	XITANIUM 50W WH 0.7-1.5A 54V TD/IS
Order code	37799800
Full product code	871951437799800
Material number (12NC)	929002862006
Full product name	Xitanium 50W WH 0.7-1.5A 54V TD/Is
Numerator - Packs per outer box	20
Numerator - Quantity Per Pack	1
EAN/UPC - Case	8719514378001

Approval and Application

Protection class IEC	Safety class I/II
Isolation Classification	Class I and Class II
Ingress protection code	IP20  [Finger-protected]
Approval Marks	CE marking	CB Certificate	ENEC certificate	CCC certificate	RCM compliance
Output Current Set Options	DALI, NFC

Controls and Dimming

Dimmable

DALI

General Information

Lighting Technology

LED

Mechanical and Housing

Overall length	201 mm
Overall height	32.5 mm
Dimensions (Height x Width x Depth)	33 x 75 x 201 mm
Overall width	75 mm
Product Length	200 mm

Temperature

T-Case Maximum (Max)	90 °C
T-Case Lifetime (Max)	80 °C

System characteristics

Central DC Operation	Yes
YellowDot ready	No
