| Light source colour | 730 warm white
|
| Light source replaceable | No
|
| Number of gear units | 1 unit
|
| Driver included | Yes
|
| Optical cover/lens type | PC-MLO
[ Polycarbonate micro lens optic] |
| Control interface | -
|
| Connection | Flying leads/wires
|
| Cable | Cable 0.5 m without plug
|
| Protection class IEC | Safety class I (I)
|
| Flammability mark | F
[ For mounting on normally flammable surfaces] |
| CE mark | CE mark
|
| Warranty period | 3 years
|
| Constant light output | No
|
| Number of products on MCB (16 A type B) | 26
|
| EU RoHS compliant | Yes
|
| Light source engine type | LED
|
| Input Voltage | 220 to 240
V
|
| Input frequency | 50 to 60
Hz
|
| Initial CLO power consumption | NO
W
|
| Inrush current | 9.7
A
|
| Inrush time | 0.065
ms
|
| Power factor (min.) | 0.9
|
| Dimmable | No
|
| Housing material | Aluminum die–cast
|
| Optic material | Polycarbonate
|
| Optical cover/lens material | Polycarbonate
|
| Fixation material | Aluminium
|
| Mounting device | Spigot for diameter 42 to 60 mm
|
| Overall length | 453.8
mm
|
| Overall width | 277.2
mm
|
| Overall height | 85
mm
|
| Effective projected area | 0.11
m²
|
| Colour | Dark gray
|
| Dimensions (height x width x depth) | 85 x 277 x 454 mm
|
| Ingress protection code | IP66
[ Dust penetration-protected, jet-proof] |
| Mech. impact protection code | IK08
[ 5 J vandal-protected] |
| Surge protection (common/differential) | Surge protection level until 10
kV
|
| Initial luminous flux (system flux) | 10000
lm
|
| Luminous flux tolerance | +/-10%
|
| Initial LED luminaire efficacy | 100
lm/W
|
| Init. Corr. Colour Temperature | 3000
K
|
| Init. Colour rendering index | 70
|
| Initial chromaticity | (0.43, 0.40) SDCM < 5
|
| Initial input power | 100
W
|
| Power consumption tolerance | +/-10%
|
| Ambient temperature range | -40 to +50 °C
|
| Full product code | 871016332199800
|
| Order product name | BRP131 LED100/WW 100W 220-240V DM GM
|
| EAN/UPC – product | 8710163321998
|
| Order code | 32199800
|
| SAP numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 1
|
| SAP material | 911401697104
|
| Net Weight (Piece) | 3.299
kg
|
