| Beam angle of light source | 120
°
|
| Light source colour | 940 neutral white
|
| Light source replaceable | No
|
| Number of gear units | 1 unit
|
| Driver/power unit/transformer | PSD
[ Power supply unit with DALI interface] |
| Driver included | Yes
|
| Optic type | Wide beam office-compliant
|
| Luminaire light beam spread | 86°
|
| Control interface | DALI
|
| Connection | PIP
[ Push-in connector and pull relief] |
| Cable | -
|
| Protection class IEC | Safety class I (I)
|
| Glow-wire test | 650/30
[ Temperature 650 °C, duration 30 s] |
| Flammability mark | F
[ For mounting on normally flammable surfaces] |
| CE mark | Yes
|
| ENEC mark | ENEC mark
|
| Warranty period | 5 years
|
| Constant light output | No
|
| Number of products on MCB (16 A type B) | 30
|
| Photobiological risk | Photobiological risk group 1 @200mm to EN62778
|
| EU RoHS compliant | Yes
|
| Service Tag | Yes
|
| Product family code | RC463B
[ PowerBalance recessed] |
| Unified glare rating CEN | 16
|
| Saturated Red | >50
|
| Flickering | 1
|
| Stroboscopic effect | 0.4
|
| Input Voltage | 220 to 240
V
|
| Input frequency | 50 to 60
Hz
|
| Inrush current | 19.4
A
|
| Inrush time | 0.230
ms
|
| Power factor (min.) | 0.9
|
| UL Type | Type B – bypass the ballast
|
| Dimmable | Yes
|
| Housing material | Steel
|
| Reflector material | Polycarbonate
|
| Optic material | Polycarbonate
|
| Optical cover/lens material | Polycarbonate
|
| Fixation material | -
|
| Optical cover/lens finish | Matte
|
| Overall length | 622
mm
|
| Overall width | 622
mm
|
| Overall height | 86
mm
|
| Colour | White RAL 9003
|
| Dimensions (height x width x depth) | 86 x 622 x 622 mm
|
| Ingress protection code | IP20/40
[ Finger-protected, Emitting surface] |
|
| Mech. impact protection code | IK02
[ 0.2 J standard] |
|
| Sustainability rating | Lighting for circularity
|
Lighting for wellbeing
|
| Initial luminous flux (system flux) | 2800
lm
|
| Luminous flux tolerance | +/-10%
|
| Initial LED luminaire efficacy | 147
lm/W
|
| Init. Corr. Colour Temperature | 4000
K
|
| Init. Colour rendering index | ≥90
|
| Initial chromaticity | (0.38, 0.38) SDCM <3
|
| Initial input power | 19
W
|
| Power consumption tolerance | +/-10%
|
| Control gear failure rate at median useful life 50,000 h | 5
%
|
| Lumen maintenance at median useful life* 50,000 h | L90
|
| Lumen maintenance at median useful life* 100,000 h | L80
|
| Ambient temperature range | +10 to +40 °C
|
| Performance ambient temperature Tq | 25 °C
|
| Maximum dimming level | 1%
|
| Suitable for random switching | No
|
| Full product code | 871869996604100
|
| Order product name | RC463B LED28S/940 PSD W62L62 VPC PIP
|
| EAN/UPC – product | 8718699966041
|
| Order code | 96604100
|
| SAP numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 1
|
| SAP material | 910505100416
|
| Net Weight (Piece) | 4.900
kg
|
