    • PowerBalance gen2 – sustainable performance

      RC463B LED40S/940 PSD W31L125 CPC PIP
      LED
      RC463B LED40S/940 PSD W31L125 CPC PIP

      RC463B LED40S/940 PSD W31L125 CPC PIP

      Order code: 96442900

      Full Product Code: 871869996442900

      Downloads

      Leaflet
      Size:458.0 kB

      See all downloads

    Specifications Show all

    General Information
    Number of light sources
    1  [ 1 pc]
    Lamp family code
    LED40S  [ LED Module, system flux 4000 lm]
    Beam angle of light source
    120 °
    Light source colour
    940 neutral white
    Light source replaceable
    No
    Number of gear units
    1 unit
    Gear
    -
    Driver/power unit/transformer
    PSD  [ Power supply unit with DALI interface]
    Driver included
    Yes
    Optic type
    No  [ -]
    Optical cover/lens type
    PC  [ Polycarbonate bowl/cover]
    Luminaire light beam spread
    86°
    Control interface
    DALI
    Connection
    PIP  [ Push-in connector and pull relief]
    Cable
    -
    Protection class IEC
    Safety class I (I)
    Glow-wire test
    850/5  [ Temperature 850 °C, duration 5 s]
    Flammability mark
    F  [ For mounting on normally flammable surfaces]
    CE mark
    CE mark
    ENEC mark
    ENEC mark
    UL mark
    -
    Warranty period
    5 years
    Glare shielding accessories
    No  [ -]
    Constant light output
    No
    Number of products on MCB
    24
    EU RoHS compliant
    Yes
    Product Family Code
    RC463B  [ PowerBalance recessed]
    Unified glare rating CEN
    16
    Light Technical
    Saturated Red (R9)
    >50
    Operating and Electrical
    Input voltage
    220 to 240 V
    Input frequency
    50 to 60 Hz
    Inrush current
    21 A
    Inrush time
    0.28 ms
    Power factor (min.)
    0.9
    Controls and Dimming
    Dimmable
    Yes
    Mechanical and Housing
    Geometry
    W31L125  [ Width 0.31 m, length 1.25 m]
    Housing configuration
    CPC  [ Concealed profile ceiling version]
    Housing material
    Steel
    Reflector material
    Polycarbonate
    Optic material
    -
    Optical cover/lens material
    Polycarbonate
    Gear tray material
    Steel
    Fixation material
    -
    Optical cover/lens finish
    Matte
    Overall length
    1247 mm
    Overall width
    310 mm
    Overall height
    79 mm
    Colour
    White RAL 9003
    Dimensions (height x width x depth)
    79 x 310 x 1247 mm (3.1 x 12.2 x 49.1 in)
    Approval and Application
    Ingress protection code
    IP20 (front IP40)
    Mech. impact protection code
    IK02  [ 0.2 J standard]
    Initial Performance (IEC Compliant)
    Initial luminous flux
    4000 lm
    Initial luminous flux at color temperature of 4000 K
    4000 lm
    Luminous flux tolerance
    +/-10%
    Initial LED luminaire efficacy
    140 lm/W
    Init. Corr. Colour Temperature
    4000 K
    Init. Color rendering index
    ≥90
    Initial chromaticity
    (0.38, 0.38) SDCM <3
    Initial input power
    28.5 W
    Power consumption tolerance
    +/-10%
    Over Time Performance (IEC Compliant)
    Control gear failure rate at median useful life 50,000 h
    5 %
    Lumen maintenance at median useful life* 50,000 h
    L90
    Application Conditions
    Ambient temperature range
    +10 to +40 °C
    Performance ambient temperature Tq
    25 °C
    Maximum dimming level
    1%
    Suitable for random switching
    No
    Product Data
    Full product code
    871869996442900
    Order product name
    RC463B LED40S/940 PSD W31L125 CPC PIP
    EAN/UPC – product
    8718699964429
    Order code
    96442900
    Numerator – quantity per pack
    1
    Numerator – packs per outer box
    1
    Material no. (12NC)
    910505100236
    Net weight (piece)
    5.800 kg
    Installation Diagrams
    Photometrics
    IFGU1_RC463BPSDW31L1251xLED40S940
    IFGU1_RC463BPSDW31L1251xLED40S940
    Downloads
    Leaflets
    • Leaflet Localized commercial leaflet PDF 458.0 kB
    Visuals
    Brochures
    Software Plugins
    • IES IFMT1_RC463BPSDW31L1251xLED40S940 IES 26.9 kB
    • ULD IFDM1_RC463BPSDW31L1251xLED40S940 ULD 78.5 kB
    • Relux IFDM2_RC463BPSDW31L1251xLED40S940 ROLF 20.7 kB
    • LDT IFMT2_RC463BPSDW31L1251xLED40S940 LDT 19.7 kB
