| Lamp family code | -
|
| Beam angle of light source | 120
°
|
| Light source colour | -
|
| Cap base | -
[ -] |
| Light source replaceable | No
|
| Number of gear units | 1 unit
|
| Driver/power unit/transformer | PSU
[ Power supply unit] |
| Driver included | Yes
|
| Optic type | MB
[ Medium beam] |
| Optical cover/lens type | PM
[ PMMA bowl/cover] |
| Luminaire light beam spread | -
|
| Connection | No
[ -] |
| Cable | -
|
| Protection class IEC | Safety class I (I)
|
| Glow-wire test | 650/5
[ Temperature 650 °C, duration 5 s] |
| Flammability mark | NO
[ -] |
| CE mark | Yes
|
| ENEC mark | ENEC mark
|
| UL mark | -
|
| Warranty period | 5 years
|
| Constant light output | No
|
| Number of products on MCB (16 A type B) | 34
|
| EU RoHS compliant | Yes
|
| Service Tag | Yes
|
| Product family code | ST315T
[ GREENSPACE ACCENT PROJECTOR MINI] |
| Unified glare rating CEN | Not applicable
|
| Input Voltage | 220 to 240
V
|
| Input frequency | 50 to 60
Hz
|
| Initial CLO power consumption | - W
W
|
| Average CLO power consumption | - W
W
|
| Inrush current | 18
A
|
| Inrush time | 0.25
ms
|
| Power factor (min.) | 0.24
|
| Dimmable | No
|
| Housing material | Aluminum
|
| Reflector material | Polycarbonate aluminum coated
|
| Optic material | Polycarbonate
|
| Optical cover/lens material | Polymethyl methacrylate
|
| Fixation material | -
|
| Optical cover/lens finish | Clear
|
| Overall length | 181
mm
|
| Overall width | 80
mm
|
| Overall height | 250
mm
|
| Overall diameter | 80
mm
|
| Diameter | -
|
| Colour | Black
|
| Dimensions (height x width x depth) | 250 x 80 x 181 mm
|
| Ingress protection code | IP20
[ Finger-protected] |
| Mech. impact protection code | IK02
[ 0.2 J standard] |
| Sustainability rating | -
|
| Initial luminous flux (system flux) | 2700
lm
|
| Luminous flux tolerance | +/-10%
|
| Initial LED luminaire efficacy | 104
lm/W
|
| Init. Corr. Colour Temperature | 3500
K
|
| Init. Colour rendering index | ≥90
|
| Initial chromaticity | (0.40, 0.38) SDCM<3
|
| Initial input power | 26
W
|
| Power consumption tolerance | +/-10%
|
| Driver failure rate at 5,000 hours | 10
%
|
| Control gear failure rate at median useful life 50,000 h | 5
%
|
| Lumen maintenance at median useful life* 50,000 h | L80
|
| Ambient temperature range | +10 to +40 °C
|
| Performance ambient temperature Tq | 25 °C
|
| Suitable for random switching | Not applicable
|
| Full product code | 871869940918000
|
| Order product name | ST315T LED27S/PW935 PSU FR24 BK
|
| EAN/UPC – product | 8718699409180
|
| Order code | 40918000
|
| SAP numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 1
|
| SAP material | 910500465641
|
| Net Weight (Piece) | 0.800
kg
|
