| Number of light sources | 1
[ 1 pc] |
| Lamp family code | LED27
[ LED module 2700 lm] |
| Beam angle of light source | 120
°
|
| Light source colour | 830 warm white
|
| Cap base | -
[ -] |
| Light source replaceable | No
|
| Number of gear units | 1 unit
|
| Driver/power unit/transformer | PSU
[ Power supply unit] |
| Driver included | Yes
|
| Optic type | MB
[ Medium beam] |
| Optical cover/lens type | PM
[ PMMA bowl/cover] |
| Luminaire light beam spread | 24°
|
| Connection | No
[ -] |
| Cable | -
|
| Protection class IEC | Safety class II (II)
|
| Mounting | 3C-69
[ 3-circuit power track adapter GA69 (connection point) for XTS and XTSF tracks] |
| Glow-wire test | 650/5
[ Temperature 650 °C, duration 5 s] |
| Flammability mark | F
[ For mounting on normally flammable surfaces] |
| CE mark | CE mark
|
| ENEC mark | ENEC mark
|
| UL mark | -
|
| Warranty period | 5 years
|
| Remarks | *- According to the Lighting Europe guidance paper 'Evaluating performance of LED based luminaires – January 2018': statistically there is no relevant difference in lumen maintenance between the B50 and, for example, the B10. Therefore, the median useful life (B50) value also represents the B10 value.
|
| Constant light output | No
|
| Number of products on MCB (16 A type B) | 32
|
| EU RoHS compliant | Yes
|
| Product family code | ST320T
[ GREENSPACE ACCENT PROJECTOR] |
| Unified glare rating CEN | Not applicable
|
| Input Voltage | 220-240
V
|
| Input frequency | 50 to 60
Hz
|
| Inrush current | 18.6
A
|
| Inrush time | 0.240
ms
|
| Power factor (min.) | 0.9
|
| Dimmable | No
|
| Housing material | Aluminum
|
| Reflector material | Polycarbonate aluminum coated
|
| Optic material | Polycarbonate
|
| Optical cover/lens material | Polymethyl methacrylate
|
| Fixation material | Polyamide
|
| Optical cover/lens finish | Clear
|
| Overall length | 182
mm
|
| Overall width | 114
mm
|
| Overall height | 193
mm
|
| Colour | White
|
| Dimensions (height x width x depth) | 193 x 114 x 182 mm (7.6 x 4.5 x 7.2 in)
|
| Ingress protection code | IP20
[ Finger-protected] |
| Mech. impact protection code | IK02
[ 0.2 J standard] |
| Initial luminous flux (system flux) | 2700
lm
|
| Luminous flux tolerance | +/-10%
|
| Initial LED luminaire efficacy | 114.8936170212766
lm/W
|
| Init. Corr. Colour Temperature | 3000
K
|
| Init. Colour rendering index | ≥80
|
| Initial chromaticity | (0.43, 0.40) SDCM<3
|
| Initial input power | 23.5
W
|
| Power consumption tolerance | +/-10%
|
| Control gear failure rate at median useful life 50,000 h | 5
%
|
| Lumen maintenance at median useful life* 50,000 h | L80
|
| Ambient temperature range | +10 to +40 °C
|
| Performance ambient temperature Tq | 25 °C
|
| Suitable for random switching | Yes
|
| Full product code | 871869916660100
|
| Order product name | ST320T LED27S/830 PSU MB WH
|
| EAN/UPC – product | 8718699166601
|
| Order code | 16660100
|
| SAP numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 1
|
| SAP material | 910500459378
|
| SAP net weight (piece) | 0.980
kg
|
