| Cap base | PGZ12
[ PGZ12] |
| Operating position | UNIVERSAL
[ Any or Universal (U)] |
| Life to 5% failures (nom.) | 21500
h
|
| Life to 10% failures (nom.) | 24000
h
|
| Life to 20% failures (nom.) | 27000
h
|
| Life to 50% failures (nom.) | 32000
h
|
| ANSI code HID | C187/E
|
| LSF 2000 h Rated | 99
%
|
| LSF 4000 h Rated | 99
%
|
| LSF 6000 h Rated | 99
%
|
| LSF 8000 h Rated | 99
%
|
| LSF 12000 h Rated | 99
%
|
| LSF 16000 h Rated | 99
%
|
| LSF 20000 h Rated | 97
%
|
| LSF 24000 h Rated | 90
%
|
| LSF 30000 h Rated | 63
%
|
| Sphere
|
| Colour Code | 728
[ CCT of 2,800 K] |
| Luminous flux (nom.) | 7200
lm
|
| Luminous flux (rated) (nom.) | 7200
lm
|
| Colour designation | White (WH)
|
| Chromaticity coordinate X (nom.) | 0.447
|
| Chromaticity coordinate Y (nom.) | 0.4
|
| Correlated Colour Temperature (Nom) | 2800
K
|
| Luminous efficacy (rated) (nom.) | 120
lm/W
|
| Colour-rendering index (min.) | 70
|
| Colour rendering index (nom.) | 73
|
| LLMF 2000 h Rated | 92
%
|
| LLMF 4000 h Rated | 90
%
|
| LLMF 6000 h Rated | 90
%
|
| LLMF 8000 h Rated | 90
%
|
| LLMF 12000 h Rated | 89
%
|
| LLMF 16000 h Rated | 87
%
|
| LLMF 20000 h Rated | 86
%
|
| LLMF 24000 h Rated | 84
%
|
| LLMF 30000 h Rated | 82
%
|
| Ratio scotopic/photopic lumens | 1.15
|
| Power (Rated) (Nom) | 60.0
W
|
| Ignition peak voltage (max.) | 5000
V
|
| Re-ignition time (min.) (max.) | 900
s
|
| Ignition time (max.) | 30
s
|
| Voltage (Max) | 99
V
|
| Voltage (Min) | 85
V
|
| Voltage (Nom) | 92
V
|
| Dimmable | Yes
|
| Run-up time 90% (max.) | 3
min
|
| Lamp Finish | Clear
|
| Bulb shape | T19
[ T 19mm] |
| Energy Efficiency Class | E
|
| Mercury (Hg) content (max.) | 2
mg
|
| Mercury (Hg) content (nom.) | 2.0
mg
|
| Energy consumption kWh/1,000 hours | 60
kWh
|
| 473348
|
| PET (NIOSH) (min.) | 8
h/500lx
|
| PET (NIOSH) (nom.) | 19
h/500lx
|
| Damage factor D/fc (nom.) | 0.17
|
| Bulb temperature (max.) | 400
°C
|
| Cap-base temperature (max.) | 300
°C
|
| Cap-Base Temperature (Max)-DUP(do not use) | 572
°F
|
| Full product code | 871150020851415
|
| Order product name | MASTER CosmoWhite CPO-TW Xtra 60W/728 PGZ12
|
| EAN/UPC – product | 8711500208514
|
| Order code | 20851415
|
| SAP numerator – quantity per pack | 1
|
| Local code description | MST COSMOWH CPO-TW XTRA 60W/728 PGZ12
|
| Numerator – packs per outer box | 12
|
| SAP material | 928088505127
|
| Net Weight (Piece) | 0.034
kg
|
| ILCOS code | MT-60/728-H-PGZ12-20/132
|
